Applications:
KASON-HTPB100 digital pencil hardness tester is specially used for testing the hardness of pencil leads of various pencils, and implements the standard " GB/T 26704-2011 Pencil". This product is widely used in the domestic pencil manufacturing industry.
The main technical parameters:
Product number
KASON-HTPB100
Implementation Standards
GB/T 26704-2011 Pencil
Test force (N)
0.245, 0.49, 0.98, 1.96, 2.94, 4.98
Minimum test unit
0.01µm
Hardness test range (HK)
40-700
Test force application method
Automatic (loading, holding load, unloading)
Indenter and lens conversion
automatic
Testing Microscope Magnification
100X (observation, test) 200X (test)
Test force holding time
1~99s, 10s recommended
XY Test Table
Size: 100*100mm Maximum movement: 25*25mm
Data Output
LCD display readout, built-in printer
Workpiece effective height
100mm
Distance from the center of the pressure head to the outer wall
130mm
power supply
AC220V + 5%, 50-60Hz
Dimensions
540*260*650mm
Host weight
About 50Kg
